Revisionġ1 The Simplified Solutions Library A dimensioned print similar to the one to the right is viewable for all components All Components are in the following formats: Pro/Engineer.prt STEP IGES EMN Component Outline (for import to ECAD packages) Revisionġ2 Config.pro Settings Add the following settings to your config.pro prior to importing your IDF emn file into Pro/Engineer.
#PRO ENGINEER WILDFIRE 5.0 STL DOWNLOAD#
Generate and download your ecad_hint.map file Download the listed components that you have chosen from our library. Clicking the magnifying glass and searching our library. Choose replacement 3D models for each item by either: 1. If you have an existing ecad_hint.map, upload it as well. If working with multiple emn files, continue uploading your remaining files. Revision 1.1 9ġ0 The hint.map tool Upload your first emn file The tool will generate a table with a line item for each unique combination of the ecad_name and ecad_alt_name.
Add the proper setting to your config.pro file. Fill in the component name in the hint.map tool. For these items, either submit a component request on our website or build the 3D component on your own. Identify components that are not in our library. While in our hint.map tool, for each line item, choose a 3D replacement model from our online library. Import your.emn file to our online hint.map tool. Generate your IDF files using your ECAD tool. Revision 1.1 8ĩ Steps to create your PCB using Simplified Solutions Products 1. For surface mount components, the coordinate system is through the geometric center of the component, while for thru-hole parts, the coordinate system is through the center of pin 1. The Simplified Solutions Library of Components follows IPC-7351 with respect to component orientation. In this case, c0805h100 map_objects_by_name -> ecad_name cap0805" ecad_alt_name " ecad_type "" mcad_name c0805h100" mcad_type part end Revision 1.1 7Ĩ Matching 3D components to existing ECAD Geometries The coordinate system in all 3D Models must have the identical orientation and be in the identical location when compared to the matching ECAD Geometry. If it a match is found, Pro/Engineer will replace on the fly geometry with a real 3D Pro/Engineer part or assembly. This information gets disregarded when the Pro/ECAD User replaces this data with real 3D models Revision 1.1 6ħ The ecad_hint.map file The ecad_hint.map file links components in your ECAD Tool to 3D Pro/Engineer Models cap D BOTTOM PLACED When an IDF (emn) File is imported into Pro/Engineer, Pro/E crossreferences the ecad_name and ecad_alt name from the emn file against the ecad_hint.map. Revision 1.1 5Ħ Typical emp file entry.electrical cap THOU END_ELECTRICAL The EMP file contains information describing each component s 2D shape and height. Do not set up your ECAD IDF output to use identical ecad and ecad_alt names.
#PRO ENGINEER WILDFIRE 5.0 STL SOFTWARE#
*HINT: To maximize reuse of Mechanical Models, set up your ECAD Design Software to output a package type as the ecad_name and either an internal corporate part number or a vendor part number as the ecad_alt_name. PLACED specifies component will be added to 3D PCB. Revision 1.1 3Ĥ The IDF Files (.emn and.emp files) EMN File Contains: -PCB Outline -Component Location -Component Orientation -Hole Information -Keep In and Keep Out Regions EMP File Contains: -ECAD outlines for every component -ECAD component height information Revision 1.1 4ĥ Typical.emn file component entry cap D BOTTOM PLACED cap0805 is the ecad_name(package type recommended) is the ecad_alt_name (unique part number)* D8 is the reference designator, , and 0.0 represent the location with respect to the PCB s (0,0) point X, Y, Z directions represents the orientation of the component. An ecad_hint.map file which links ECAD geometry names to 3D Pro/Engineer.prt and.asm files. Each component must have the identical coordinate system location and orientation when compared to the ECAD Geometry.
Revision 1.1 2ģ Files Required to create your 3D PCB IDF (Intermediate Data) Files in version 2.0 or 3.0 generated in your ECAD tool.
Link the ECAD Data for each component to its corresponding 3D model. Create or identify a matching 3D Pro/Engineer model for every ECAD component. Gather the ECAD Data and locate specifications for each component on the PCB. 1 Creating a 3D PCB in Pro/Engineer If you have any questions or comments please contact: Keith Richman Simplified Solutions Inc (410) /19/2008 Revision 1.1 1Ģ Basic steps to create your 3D PCB in Pro/Engineer 1.
